A Rust distributed filesystem for object storage, POSIX workloads, and isolated agent workspaces.

Quick Start · Agent Workspaces · Architecture · Performance · Documentation · 中文

BrewFS exposes a Linux filesystem through FUSE while keeping metadata and file data independently deployable. Metadata can live in Redis, TiKV, etcd, PostgreSQL, or SQLite; immutable data blocks can live in S3-compatible object storage or on a local filesystem.

The project is built as one Rust data path from FUSE and VFS through caching, writeback, metadata transactions, and object storage. BrewFS is independent: RustFS, MinIO, AWS S3, and Ceph RGW are supported S3-compatible backends, not parts of BrewFS itself.

[!IMPORTANT] BrewFS is under active development. The regular flat-v1 volume is the default. Agent-oriented workspace-v1 volumes are implemented behind the optional workspace-overlay Cargo feature while their operational tooling continues to mature.

Why BrewFS

• Object-storage-native data path. Files are split into 64 MiB chunks and 4 MiB blocks, with immutable objects below a transactional namespace.
• Tiered read and write acceleration. Linux page cache, BrewFS memory cache, SSD cache, read-ahead, writeback staging, and large-write coalescing work together instead of treating object storage as a block device.
• Isolated agent sandboxes. Workspace Overlay lets agents share one sealed base while keeping namespace, inode, xattr, ACL, and extent changes private.
• Deployable in stages. Start with SQLite and local data, move metadata to a distributed backend, then attach any supported S3-compatible store.
• Correctness is measured. The repository carries Rust tests, xfstests, pjdfstest, LTP, stress-ng, fio, fuzzing, and repeatable Docker Compose runners.
• Read amplification is controlled. The current read path checks memory and Linux page-cache hits before local disk cache access, serves persistent slices by range, and tracks buffered FUSE fragments per handle. A complete block is promoted only after reuse is observed, while high-concurrency lookahead stays private to avoid polluting the shared cache.
• Observable operations. Runtime statistics, info, gc, writeback accounting, and profiling hooks make performance and recovery behavior inspectable.

Quick Start

Install a complete single-node stack

On Linux, the installer provisions BrewFS, Redis, RustFS, systemd services, and a FUSE mount at /mnt/brewfs:

curl -fsSL https://cdn.jsdelivr.net/gh/brewfs/brewfs@main/scripts/install_brewfs_single_node.sh \
  | sudo bash -s -- install

Verify the services and mount:

sudo systemctl status brewfs.service brewfs-redis.service brewfs-rustfs.service
mountpoint /mnt/brewfs
sudo /usr/local/bin/brewfs info /mnt/brewfs

The same installer supports status, restart, upgrade, and uninstall. Set MOUNT_POINT, BREWFS_VERSION, or BREWFS_TUNING_PROFILE to customize the installation. See the binary deployment guide before using the stack for persistent data.

Build a local development mount

Requirements: Linux, FUSE 3, and Rust 1.85 or newer.

cargo build -p brewfs --release

mkdir -p /tmp/brewfs-mnt /tmp/brewfs-data
target/release/brewfs mount /tmp/brewfs-mnt \
  --data-backend local-fs \
  --data-dir /tmp/brewfs-data \
  --meta-backend sqlx \
  --meta-url 'sqlite:///tmp/brewfs-meta.db?mode=rwc'

In another terminal:

touch /tmp/brewfs-mnt/hello
target/release/brewfs info /tmp/brewfs-mnt
fusermount3 -u /tmp/brewfs-mnt

For S3 credentials, cache sizing, writeback modes, FUSE workers, and YAML configuration, use the configuration reference.

Agent Workspaces

AI coding agents often begin from the same checkout but need private, short-lived mutations. Copying an entire filesystem per agent wastes time and object capacity; sharing one writable mount weakens isolation.

BrewFS Workspace Overlay provides a filesystem-native alternative:

1. A sealed base holds the shared namespace and immutable object blocks.
2. Each agent gets one private writable overlay.
3. Forking creates metadata and a new writable head; it does not copy clean object data.
4. diff, snapshot, fast-forward commit, and lease-aware discard make changes explicit.
5. Backend-time leases and generation fencing prevent a stale mount from writing after ownership changes.

flowchart LR
    Base[Sealed base revision] --> A[Agent A private overlay]
    Base --> B[Agent B private overlay]
    Base --> C[Agent C private overlay]
    A --> Commit[Review / commit]
    B --> Discard[Discard]
    C --> Snapshot[Snapshot / fork again]
    Base -. shared immutable blocks .-> Objects[(Object storage)]

The feature is opt-in and does not alter regular flat volumes:

cargo build -p brewfs --release --features workspace-overlay
target/release/brewfs workspace --help

The CLI exposes init-volume, create, snapshot, fork, list, inspect, diff, commit, and discard. Redis and TiKV are the distributed catalog backends; SQLite is available for local semantics and development. Every mounted workspace resolves exactly two layers: one private writable head and one fixed sealed base.

Current boundaries are intentional: the feature is off by default, workspace-v1 never falls back to flat-volume behavior, workspace statfs waits for atomic usage counters, and the WebDAV gateway currently accepts only flat-v1. Read the Workspace Overlay architecture before building an operator or multi-agent service around it.

Architecture

flowchart LR
    Apps[Applications] --> VFS[Linux VFS / FUSE]
    VFS --> Brew[BrewFS VFS]
    Brew --> Meta[Transactional metadata]
    Meta --> MetaDB[(SQLite / PostgreSQL<br/>Redis / etcd / TiKV)]
    Brew --> Cache[Chunk and cache layer]
    Cache --> Memory[Memory cache]
    Cache --> SSD[SSD cache and writeback]
    Cache --> Objects[(S3-compatible<br/>or local object data)]
    Brew --> Control[info / gc / metrics]

• FUSE + VFS implement inode-based filesystem operations, permissions, locks, links, sparse files, truncate, and rename.
• Metadata stores namespaces, attributes, slices, sessions, and transactions independently from object data.
• Chunk + cache resolve file extents into immutable blocks and coordinate memory caching, persistent caching, ranged slice reads, read-ahead, confirmed block promotion, writeback, compaction, and GC.
• Gateways can expose flat volumes through S3 or WebDAV without requiring each client to mount FUSE.

See the architecture guide, read path, write path, and consistency model.

Performance

The current public baseline is the aligned Aliyun run from 2026-09-22. BrewFS and JuiceFS 1.4.1 used the same ECS specification, image, disk class, region, OSS internal path, fio workload, and aggregate cache budgets. Both ran buffered io_uring with direct=0, iodepth=1, and 4 MiB fio blocks. Each side had 4 GiB of memory cache and 8 GiB of SSD cache. All 11 tools passed.

Reads below are measured throughput. Workloads containing writes use fully-drained throughput: actual bytes divided by active I/O time plus the time required to empty the filesystem writeback queue.

Workload	BrewFS	JuiceFS 1.4.1	BrewFS delta
Large read	334.42 MiB/s	328.94 MiB/s	+1.7%
Sequential read	1,814.4 MiB/s	1,321.6 MiB/s	+37.3%
Random read	2,510.7 MiB/s	1,773.3 MiB/s	+41.6%
Large write, fully drained	217.55 MiB/s	208.26 MiB/s	+4.5%
Sequential write, fully drained	320.43 MiB/s	184.57 MiB/s	+73.6%
Random write, fully drained	328.73 MiB/s	198.31 MiB/s	+65.8%
Mixed random I/O, fully drained total	475.77 MiB/s	190.55 MiB/s	+149.7%

Methodology, read-path evidence, and limits

• Big read uses one warmup plus three measured passes. The mount is recreated and local cache-file pages are evicted between measured passes.
• BrewFS used a Linux 6.8.12 kernel carrying the upstream FUSE io_pages fix, max_read=4 MiB, and BREWFS_FUSE_READ_DIRECT_IO=0. This keeps the Linux page cache instead of using direct I/O to bypass the old 256 KiB split.
• Sequential read recorded a 100% BrewFS block-cache hit rate and zero object GETs. Random read recorded 99.9% cache hits and 16 object GETs. FUSE read bytes divided by cache requests were about 1 MiB in both workloads; cache request counts are not presented as exact FUSE operation counts.
• Write drain was 4/4/2/2 seconds for BrewFS and 4/127/118/91 seconds for JuiceFS across large, sequential, random, and mixed writes.
• Throughput is not the whole result. BrewFS random-write and mixed-write p99 were 463.471 ms and 492.831 ms, versus 92.799 ms and 10.945 ms for JuiceFS. Reducing foreground write tail latency is an explicit optimization target.
• JuiceFS 1.4.1 did not support the requested max-downloads setting; the runner records it as unsupported rather than treating it as active.
• The current main read path includes PR #135 and PR #136: page-cache hits are checked before disk-cache fallback, persistent-slice reads can avoid premature full-block promotion, and buffered FUSE fragments use private lookahead before promoting a confirmed full block. These changes reduce redundant pread and cache-fill work without changing the negotiated FUSE request size.
• Mount .stats exposes exact brewfs_fuse_read_ops_total and brewfs_fuse_read_bytes_total counters, alongside brewfs_read_page_cache_hits_total, brewfs_read_block_cache_hits_total, and brewfs_persistent_slice_read_{ops,bytes}_total. Use these counters when explaining a performance result; cache requests are not FUSE call counts.

Result Vault:

• BrewFS: run-20260922-130750-c50cef22
• JuiceFS: run-20260922-135411-77149372

These are single-configuration engineering results, not a universal performance claim. Reproduction details live in the Aliyun performance guide and the benchmark guide.

Correctness and Testing

Performance changes are accepted only with correctness and mixed-I/O gates. The maintained validation baseline includes:

Suite	Current maintained baseline
Rust workspace tests	Unit and integration coverage across VFS, caches, metadata, gateways, and workspace overlay
xfstests	708 configured cases passed on SQLite, Redis, etcd, and TiKV profiles
pjdfstest	246 files and 9,134 assertions passed on Redis and TiKV, with no default exclusions
LTP filesystem profiles	Passed across all four metadata backends with documented exclusions
Stress and performance	stress-ng plus fio read, write, mixed-I/O, latency, cache, and drain accounting

The word “configured” matters: kernel/FUSE limitations and unsupported operations remain documented rather than being counted as passes. See the filesystem test matrix for artifacts, exclusions, and known limitations.

Run the fast local gate:

cargo test -p brewfs

cd docker
bash compose-xfstests/run_redis_xfstests.sh --cases "generic/001"
bash compose-xfstests/run_redis_pjdfstest.sh

The Docker Compose testing guide covers Redis, TiKV, RustFS, xfstests, pjdfstest, LTP, stress-ng, fio, and performance profiling.

Roadmap

These are current priorities, not release guarantees:

• v0.1.3 release: validate the Quick Start on a clean host, publish the current main binaries, and keep the README/performance baseline aligned with the merged read-path work.
• Agent workspace productization: operator-managed lifecycle, atomic usage accounting for statfs, simpler workspace mount UX, and gateway support without weakening layer isolation or fencing.
• Predictable write latency: preserve fully-drained throughput while reducing random and mixed-write p99 through better queue fairness, backpressure, and foreground/background resource isolation.
• Multi-client confidence: broaden concurrent-client, failure-recovery, lease-expiry, and rolling-upgrade testing.
• Read-path portability: detect kernels with the FUSE io_pages fix, retain a safe compatibility mode for older kernels, and expose exact request-size observability.
• Ecosystem: continue hardening S3 and WebDAV gateways, deployment tooling, metrics, and workload-specific profiles.

Documentation

• Documentation index
• Architecture
• Workspace Overlay
• Configuration
• Binary deployment
• Observability
• S3 and WebDAV gateways
• Benchmark guide

Contributing

Issues and pull requests are welcome. Keep behavior changes, tests, and documentation together. Performance changes should include reproducible artifacts and must not move work invisibly from fio runtime into close, flush, or background drain.

License

BrewFS is available under the MIT License.
