Bloq

Turning a logical algorithm into an executable surface code program requires several compilation stages:

Bloq compiles surface code spacetime layouts into physical programs with the circuit, decoding, and classical-control information needed for simulation and hardware execution. It connects the logical layout to a physical instruction stream that combines quantum operations with classical control.

The input is a BlockGraph: a 3D spacetime layout composed of primitive logical blocks and actions such as measurement-controlled branches and logical Pauli feedback. The same graph can own reusable definitions, placed instances, and their quantum and classical interfaces. Loading and saving retain that hierarchy; one compile API handles both local and composed graphs. The output is Bloq IR, which records physical gates, detectors, logical observables, classical control, and source provenance.

Bloq provides Rust and Python APIs, a CLI, and an interactive editor.

Start with the documentation or open the browser editor.

Feature highlights

• Surface Code Building Blocks Compose cubes for memory and lattice surgery, patch rotations, walking patches (sliding or gliding), Y-basis initialization and measurement, logical Hadamards, and T-state cultivation.
• Dynamic Quantum-Classical Computation Express logical measurements, classical bindings, Pauli feedback, measurement-controlled branch selection, repeat-until-success regions, and shot discard.
• Reusable Modules Define logical components such as AND, MAJ, and UMA independently, then compose and link them into larger computations such as adders, retaining their quantum and classical interfaces.
• Correlation Surfaces A shared logical model tracks measurement signs, byproduct operators, and authored feedback across modules and reachable branches, deriving corrected readouts and output Pauli frames together.
• Physical Circuits And Decoding Information Block and pipe constructions have physical circuit realizations with detector and logical-observable information for downstream decoding and correction.
• An Editable Physical IR Rust and Python APIs expose physical operations, control dependencies, and provenance. Use the IR for backend emission, causal timing and synchronization, and memory-round padding.

Relationship with TQEC

Bloq grew out of work on TQEC and is a substantial Rust rewrite and extension of its block-graph compilation approach. Its design focuses on reusable modules, explicit physical-program semantics, and dynamic classical control.

Installation

Install the CLI with Cargo:

cargo install bloq-cli --version 0.1.1 --locked

Or install the CLI in an isolated Python environment with uv (Python 3.10 or newer):

uv tool install "bloq-py==0.1.1"

For a Rust project:

cargo add bloq@=0.1.1

For a Python project (Python 3.10 or newer):

pip install "bloq-py==0.1.1"

The Python distribution is bloq-py; the import and CLI remain bloq.

See Contributing and the installation guide for source builds, development setup, and editor prerequisites.

Usage

This example implements a logical T gate. The purple block represents T-state cultivation, then lattice surgery implements the MZZ parity measurement between the T state and the data qubit. The MZZ outcome selects whether we measure the consumed T state in the X or Y basis.

Explore the interactive T-gate block graph.

Save the following BLOG source as t-gate.blog:

BLOG 1.0

module main {
  in q_in: data = 0
  out q_out: data = 2

  0: Port [0, 0, 0]
  1: XZX [0, 0, 1]
  2: Port [0, 0, 2]
  3: T [1, 0, 0]
  4: XZX [1, 0, 1]
  5: YX [1, 0, 2]
  [0, 0, 0] -> +Z
  [0, 0, 1] -> +Z
  [0, 0, 1] -> +X
  [1, 0, 0] -> +Z
  [1, 0, 2] -> -Z

  mzz = measure 1 -> +X
  resolve 5 if mzz
}

The examples below compile this layout at code distance 11 and save Bloq IR, which retains its dynamic control flow.

CLI

bloq compile t-gate.blog -d 11 --backend ir-text -o t-gate.bloqir
bloq validate t-gate.bloqir
bloq view t-gate.blog --html

Rust

use bloq::prelude::*;

fn main() -> Result {
    let graph = BlockGraph::load("t-gate.blog")?;
    let program = compile(&graph, 11)?;
    std::fs::write("t-gate.bloqir", program.to_text())?;
    Ok(())
}

Python

import bloq

graph = bloq.BlockGraph.load("t-gate.blog")
program = bloq.compile(graph, distance=11)
program.save("t-gate.bloqir")

Compiled Bloq IR records physical gates, detectors, logical observables, classical control, and source provenance. This T-gate program also retains basis selection, output Pauli frames, and the cultivation retry region.

Documentation

The documentation is hosted on the Bloq website. Some quick links are shown below:

• Getting started
• User Guide
• CLI reference
• Python API
• Rust API
• Browser editor

Contributing

See CONTRIBUTING.md for development setup and verification.

Citation

If you use Bloq in your work, please cite the software repository:

@misc{zhang2026bloq,
  author       = {Zhang, Yiming},
  title        = {{Bloq}: Compiling dynamic Clifford+T surface code computations to fault-tolerant programs.},
  year         = {2026},
  howpublished = {GitHub repository},
  url          = {https://github.com/inmzhang/bloq}
}

Our paper describing Bloq will be available soon.

AI Acknowledgement

Generative AI tools assist Bloq’s software development and documentation, including drafting and reviewing code, analyzing implementations, and editing prose. Human contributors remain responsible for design, correctness, validation, and release decisions. See the AI contribution policy for review and disclosure requirements.
